The SEQUOIA™ fire hydrant, by AMERICAN Flow Control® incorporates more than a century of experience in design, manufacture and field experience from the iconic American-Darling and Waterous brands. This means dependable and efficient operation when needed.
The SEQUOIA hydrant is rated at 350 psig and is tested at 700 psig. This hydrant meets or exceeds all requirements of ANSI/AWWA C503 for wet-barrel hydrants.
SEQUOIA is manufactured with the features you expect from a high-quality fire hydrant. The exclusive nozzle retention design ensures the hydrant is easily repaired by just one person in the event of damage to the nozzles.
The SEQUOIA fire hydrant is Certified to NSF/ANSI/CAN 61 and NSF/ANSI/CAN 372, which exhibit compliance with U.S Safe Drinking Water Act.
Fire hydrants shall meet or exceed ANSI/AWWA C503, latest revision. Rated working pressure shall be 350 psig, test pressure shall be 700 psig and hydrants shall include the following specific design criteria:
Hydrant barrels shall be made of ductile iron. All pumper and hose nozzles shall be retained by a single piece threaded ductile iron retainer. Threaded-in nozzles and nozzles using set screws or wedge pins are not allowed. Nozzle caps and stem nuts shall be ductile iron and available with 1-1/8" and 1-1/2" pentagons.
Hydrant shall be wet-barrel construction with individually valved outlets. Pumper and hose valve stems and stuffing boxes shall be interchangeable. Valve disc and disc components shall be from bronze alloys. All valve washers and resilient seals shall utilize EPDM rubber.
The hydrant barrel exterior shall be factory coated with Electrodeposition (E-coat) epoxy primer and catalyzed two-part polyurethane top coating. The wetted surfaces of the hydrant barrel interior shall be coated with Fusion Bonded Epoxy and be compliant with ANSI/AWWA C550.
Hydrant shall be UL Listed and FM Approved. All hydrants are to be Certified to NSF/ANSI/CAN 61 and NSF/ANSI/CAN 372.
Hydrant to be supplied with a 2-D bar code, or similar, capable of allowing a seamless enrollment of the manufacturing attributes and hydrant location into a cloud-based GIS application, AFC Mapper Pro, or equal.
Hydrants shall be SEQUOIA™ by AMERICAN Flow Control®, or approved equal.
